- Size: 42
- Place of Origin: Longyan,Fujian
- Brand Name: FULONGMA
- Model Number: ZTX16
- Weight: 6100.000 kg
Main Characteristic | ||||||||||
A. Installing the side feeding door safety device to the ensure safety when all system stops working in the open state of side feeding door. B. Equipped with the power key lock and all cases of emergency stop button to improve safety performance. |
Fujian Longma Environmental Sanitation Equipment Co.,LTD
Add: Economic Development Zone, Longyan, Fujian Province, China.
Contact: Reese Chen ( 86 13328743040)
Tel: 86 597 2330358 Fax: 86 597 2790126
E-mail:flm_obd@fjlm.com.cn
www.fjlm.com.cn
- Size: 42
- Place of Origin: Longyan,Fujian
- Brand Name: FULONGMA
- Model Number: ZTX16
- Weight: 6100.000 kg
Parameter | ZTX16 |
Dimension (m³) | 6809*2543*2525 |
Gross Bin Weight (t) | about 6.1 |
Payload Volume (m³) | 16 |
Compressiong Tank Volume (m³) | over1.3 |
Waste Water Tank under Compression Tank (L) | over 52 |
Compression Model | Double Lil Cylinder with Cutlery Layout |
Max Compression Force (KN) | 340 |
Cycle Time of Compression (s) | less than 35 |
Garbage Lifting Device | Can lift the Standard Garbage Tank of Volume 240L、660L、1100L and 1.2 m3 Receiving Hopper |
Max Working Pressure of Hydraulic System (MPa) | 16 |
External Power Voltage (V) | 380 |
Motor Power (kw) | 7.5 |
Operation Mode | Electronic Control in the Tank |
