- Size: 12
- Place of Origin: Longyan, Fujian
- Brand Name: FULONGMA
- Model Number: FLM5020TSLC4
- Weight: 16000.000 kg
Main Characteristic | ||||||||||
|
Fujian Longma Environmental Sanitation Equipment Co.,LTD
Add: Economic Development Zone, Longyan, Fujian Province, China.
Contact: Reese Chen ( 86 13328743040)
Tel: 86 597 2330358 Fax: 86 597 2790126
E-mail:flm_obd@fjlm.com.cn
www.fjlm.com.cn
- Size: 12
- Place of Origin: Longyan, Fujian
- Brand Name: FULONGMA
- Model Number: FLM5020TSLC4
- Weight: 16000.000 kg
Parameter | FLM5020TSLC4 |
Chassis Type | CHANGAN SC1022DB4N |
National Emission Standard | EURO Ⅳ |
Engine Model Power KW | JL466Q4/ 39KW |
Dimension (mm) | 4100* 1600 * 1895 |
Gross Vehicle Weight (kg) | 1810 |
Unladen Weight (kg) | 1635 |
Payload Weight (kg) | 110 |
Wheel Base (mm) | 2500 |
Front/Rear Overhang (mm) | 480/1120 |
Approach/Departure Angle (°) | 58/18 |
Max Speed (km/h) | 75 |
Garbage Container Volume (m³) | 1.6 |
Water Tank Volume (L) | 370 |
Sweeping Width (m) | 2.1 |
Working Speed Range (km/h) | 3.5-20 |
Size of the Largest Inhaled Garbage (mm) | 120 |
Sweeping Efficiency (%) | 96 |
Dustbin Maximum Tipping Angle (°) | over 45 |
